Vertical Float Switch - 10 Foot - 1 to 6 Inch Pumping Range - Normally Open - 120 VAC Piggyback Plug
The MDI Vertical Series Pump Switch. This switch has a snap action that is rated for 13 AMPS @ 120/240 VAC and 1/2 HP @ 120/240 VAC.
This float has a 120 VAC Piggyback Plug, where no junction boxes or complicated electrical connections are needed. Plug the switch into a standard 120 VAC outlet, and plug your pump into the piggyback plug.
This switch is very customizable and very durable.
VS-120R1R9L-01 Spec Sheet
Manufacturer: MDI Sewage Products
Weight: 1.42 lb
Stock Quantity: Made to Order
Delivery: Ships in 3-5 Business Days
1 to 9
10 to 24
25 to 49
50 to 99
This Vertical Switches Features are as follows:
- Normally Open (Pump Down)
- 13 AMPS @ 120 VAC
- 1/2 HP @ 120 VAC
- Cord Length:
- Piggyback Plug
- Pumping Range:
- Enclosure and guide is ABS plastic. Float black polypropylene.
- Stainless Steel pipe mount bracket allows for mounting to standard size sump discharge piping. (Using standard mounting holes for #8 screws on 2.06" centers are located under the housing)
