Non-Clog - 6" Discharge - 18 to 60 HP - 3" Solids
SKU: CP6NC Series
- Catalog Sheet
- Specification Sheet
- Installation Manual
- Up to 238'
- 2,200 GPM
- 6" 125 Pound Horizontal Flange
- 104°F (40°C) Continuous
- Cast Iron ASTM A-48 Class 30
- Bronze
- Cast Iron ASTM A-48 Class 30
- Cast Iron ASTM A-48 Class 30
- Design
- 1 Vane Closed with Vane on Back Side
- For 18HP, 24HP, 30HP, & 36HP Versions
- 2 Vane Closed with Vanes on Back Side
- Material
- Cast Iron ASTM A-48 Class 30
- 416 Series Stainless Steel
- Buna-N
- Air Dry Enamel
- Water Based
- Design
- Double Mechanical
- Oil Filled Chamber
- Material
- Silicon Carbide Outboard Seal
- Carbon Ceramic Inboard Seal
- Buna-N Elastomer
- Stainless Steel Hardware
- 300 Series Stainless Steel
- Buna-N
- 25' Cord
- Sealed Against Moisture
- Upper
- Single Row Ball
- Oil Lubricated
- For Radial Load
- Lower
- Single Row Ball
- Oil Lubricated
- For Radial and Thrust Load
- NEMA B
- 3-Phase
- 230 & 460 Volts @ 60 Hz
- 1,750 RPM
- Oil Filled
- Requires Overload Protection to be Included in Control Panel
- Normally Open Included
- Normally Closed Included
- Impeller Trimming
- Additional Cord
- Tungsten Carbide Seal
- Slide Rail Coupling
Manufacturer: Champion Pump
Stock Quantity: In Stock
Delivery: Ships in 2-3 Business Days
Please use the "Request a Quote" form
| Model |
HP |
Voltage |
Phase |
RPM |
Max.
AMPS |
Locked
Rotor Amps |
NEMA
Code |
Cord
Size |
Cord
Type |
Cord
Length |
Pump
Weight |
| CP6NC18034 |
18 |
230 |
3 |
1,750 |
50.6 |
232 |
F |
2/3 |
G |
25' |
891 LBS |
| CP6NC18044 |
18 |
460 |
3 |
1,750 |
25.3 |
116 |
F |
2/3 |
G |
25' |
891 LBS |
| CP6NC24034 |
24 |
230 |
3 |
1,750 |
62.8 |
290 |
E |
2/3 |
G |
25' |
928 LBS |
| CP6NC24044 |
24 |
460 |
3 |
1,750 |
31.4 |
145 |
E |
2/3 |
G |
25' |
928 LBS |
| CP6NC30034 |
30 |
230 |
3 |
1,750 |
75.8 |
364 |
E |
2/3 |
G |
25' |
985 LBS |
| CP6NC30044 |
30 |
460 |
3 |
1,750 |
37.9 |
182 |
E |
2/3 |
G |
25' |
985 LBS |
| CP6NC36034 |
36 |
230 |
3 |
1,750 |
90 |
434 |
E |
2/3 |
G |
25' |
992 LBS |
| CP6NC36044 |
36 |
460 |
3 |
1,750 |
45 |
217 |
E |
2/3 |
G |
25' |
992 LBS |
| CP6NC48044 |
48 |
460 |
3 |
1,750 |
65 |
390 |
E |
2/3 |
G |
25' |
1,014 LBS |
| CP6NC60044 |
60 |
460 |
3 |
1,750 |
78 |
363 |
E |
2/3 |
G |
25' |
1,052 LBS |
